Type : MS-WS-037

Wave Spring Mechanical Seals

Wave Spring Seals are designed for bi-directional use and work with highly viscous, abrasive media, water, oils, fuels, light aggressive chemical substances and liquids containing solid particles. Most of the components are interchangeable, hence it proves economical and easy to maintain. All components are held together by snap ring which helps in easier installation and removal.

Wave Spring Mechanical Seals

Operating Limits

Shaft Dia 24mm to 100mm
Pressure 16 bar (Max)
Temperature -45° C to +180° C
Speed Max 20 m/s

Characteristics

  • Unbalanced / Balanced
  • Single acting
  • Inside mounting
  • Wave spring loaded
  • Independent of direction of rotation

Material of Construction

  • Face Materials : Tungsten Carbide, Carbon, Silicon Carbide, Ceramic, Special Cast.
  • Secondary Seal : Viton, PTFE, EPDM, NBR, FKM.
  • Metal Components : S.S 304, S.S 316.

Features

  • Wave spring design
  • Consistent sealing pressure
  • Excellent durability
  • Easy installation
  • Wide temperature range

Application

  • Sugar
  • Waste Water
  • Oil Refinery
  • Paper & Pulp Industries
  • Petrochemicals
