Type : MS-MS-026

Multi Spring Mechanical Seals

Multi Spring Seals can be used in various industries for different applications. As per the requirement of the products it can be used as single, back to back, face to face or tandem arrangement. Multiple spring usage puts uniform force over the faces hence increasing seal life. Most of the components are interchangeable, hence it proves economical and easy to maintain. All components are held together by snap ring which helps in easier installation and removal.

Multi Spring Mechanical Seals

Operating Limits

Shaft Dia 25mm to 100mm
Pressure 16 bar (Max)
Temperature -60° C to +200° C
Speed Max 20 m/s

Characteristics

  • Single acting
  • Stable drive pin
  • Inside mounting
  • Multi spring design
  • Independent of direction of rotation

Material of Construction

  • Face Materials : Tungsten Carbide, Carbon, Silicon Carbide, Ceramic, Special Cast.
  • Secondary Seal : Viton, TTV, FKM, NBR, EPR, PTFE.
  • Metal Components : S.S 304, S.S 316, Alloy 20, Hastelloy C.

Features

  • Balanced sealing pressure
  • High reliability
  • Easy installation
  • Excellent chemical compatibility
  • Versatile applications

Application

  • Process Industries
  • Oil Refinery
  • Pharmaceutical
  • Distilleries
  • Paper & Pulp Industries
