Type : MS-GLR-049

Glass Lined Reactor Mechanical Seals

Cartridge Seals designed for Glass Lined Reactors (GLR) are best suited for highly corrosive media. These seals are so designed that no metal parts comes in contact with the process media, hence no corrosion or scaling takes place on the seal parts. Both Single & Double options are available with bearing support.

Glass Lined Reactor Mechanical Seals

Operating Limits

Shaft Dia 30mm to 100mm
Pressure 10 bar (Max)
Temperature -40° C to +180° C
Speed Max 10 m/s

Characteristics

  • Standard Design
  • Double Mechanical seal
  • Cartridge Unit
  • Independent of direction of rotation
  • Operated with pressurized barrier fluid
  • Top entry Glass Lined Reactor

Material of Construction

  • Face Materials : Tungsten Carbide, Carbon, Silicon Carbide, Ceramic.
  • Secondary Seal : Viton, EPDM, Silicon, Grafoil, PTFE, FFKM.
  • Metal Components : S.S 304, S.S 316, Alloy 20, Hastelloy C.

Features

  • Seat rotating
  • Stationary springs
  • Double seal Balanced
  • Standard version with grooves optional
  • Does not open in the event of buffer pressure failure

Application

  • Chemical Processing
  • Power Plant
  • Refinery Industry
  • Petrochemicals
  • Pharmaceuticals
